Press Machines

8-22sg
8-22 SINGLE GOB
  • 8 Stations - Mould Radio: 22" (558.8 mm).
  • Oil bath Geneva Drive System.
  • Gear Box & Rotator Assembly.
  • Hollow Table.
  • External Oil "Viking Pump" for Gearbox.
  • Mechanical Clutch with pneumatic assistance.
  • Tandem Press System.
  • Electronic Timing & Drive.
  • Mould Wind Drum.
  • Press Support Yoke.
  • Stainless Steel pneumatic piping.
  • Two (02) Kick ups.
  • Mechanical Take Out Mechanism & Support.
  • SG Quick Change Block Mould Supports.



16-38sg
banderitas
12-26 SINGLE GOB
  • 12 Stations - Mould Radio: 26" (660.4 mm).
  • Oil bath Geneva Drive System.
  • Gear Box & Rotator Assembly.
  • Standard or Hollow Table.
  • External Oil "Viking Pump" for Gearbox.
  • Mechanical Clutch with pneumatic assistance.
  • Tandem Press System.
  • Electronic Timing & Drive.
  • Mould Wind Drum.
  • Press Support Yoke.
  • Stainless Steel pneumatic piping.
  • Two (02) Kick ups.
  • Mechanical Take Out Mechanism & Support.
  • SG Quick Change Block Mould Supports.



24-26 DOUBLE GOB
  • 24 Stations - Mould Radio: 26" (660.4 mm).
  • Oil bath Geneva Drive System.
  • Gear Box & Rotator Assembly.
  • Standard or Hollow Table.
  • External Oil "Viking Pump" for Gearbox.
  • Mechanical Clutch with pneumatic assistance.
  • Tandem Press System.
  • Electronic Timing & Drive.
  • Mould Wind Drum.
  • Press Support Yoke.
  • Stainless Steel pneumatic piping.
  • Four (04) Kick ups.
  • DG Mechanical Take Out Mechanism & Support.
  • DG Quick Change Block Mould Supports.



24-30 DOUBLE GOB
  • 24 Stations - Mould Radio: 30 " (762 mm).
  • Oil bath Geneva Drive System.
  • Gear Box & Rotator Assembly.
  • Standard or Hollow Table.
  • External Oil "Viking Pump" for Gearbox.
  • Mechanical Clutch with pneumatic assistance.
  • Tandem Press System.
  • Electronic Timing & Drive.
  • Mould Wind Drum.
  • Press Support Yoke.
  • Stainless Steel pneumatic piping.
  • Four (04) Kick ups.
  • DG Mechanical Take Out Mechanism & Support.
  • DG Quick Change Block Mould Supports.
16-38 SINGLE GOB
  • 16 Stations - Mould Radio: 38 " (965.2 mm).
  • Oil bath Geneva Drive System.
  • Gear Box & Rotator Assembly.
  • Hollow Table.
  • External Oil "Viking Pump" for Gearbox.
  • Mechanical Clutch with pneumatic assistance.
  • Tandem Press System.
  • Electronic Timing & Drive.
  • Mould Wind Drum. Press Support Yoke.
  • Stainless Steel pneumatic piping.
  • Mechanical Take Out Mechanism & Support.
  • Iris Supports.



banderitas
mdp12-26_web_ok
banderitas
mdp24-26_web_ok
banderitas
24-30dg
banderitas
mdp 16-30_web_ok
16-30 SINGLE GOB
  • 16 Stations - Mould Radio: 30 " (762 mm).
  • Oil bath Geneva Drive System.
  • Gear Box & Rotator Assembly.
  • Hollow Table.
  • External Oil "Viking Pump" for Gearbox.
  • Mechanical Clutch with pneumatic assistance.
  • Tandem Press System.
  • Electronic Timing & Drive.
  • Mould Wind Drum.
  • Press Support Yoke.
  • Stainless Steel pneumatic piping.
  • Mechanical Take Out Mechanism & Support.
  • Iris Supports.



banderitas
prensamdp12-30-glassplus
12-30 SINGLE GOB
  • 12 Stations - Mould Radio: 30 " (762 mm).

  • Oil bath Geneva Drive System.

  • Gear Box & Rotator Assembly.

  • Hollow Table.

  • External Oil "Viking Pump" for Gearbox.

  • Mechanical Clutch with pneumatic assistance.

  • Tandem Press System.

  • Electronic Timing & Drive.

  • Mould Wind Drum.

  • Press Support Yoke.

  • Stainless Steel pneumatic piping.

  • Mechanical Take Out Mechanism & Support.
